Ultra Light and Mini FPV Camera CM100V

Features of Ultra Light and Mini FPV Camera:
Super light and super mini camera:
9.5X9.5X12mm
1Gram only of the camea without cable
High definition micro CCTV camera,520TVL
0.008lux,can view clearly in almost complete darkness
Double lens-day& night offered

Specifications of Ultra Light and Mini FPV Camera:
SENSOR : 1/3  CMOS
SYSTEM:     NTSC: 656× 492    PAL: 768× 576
HORIZONTAL RESOLUTION: 520TVL
Exellent night vision of 0.008Lux/F1.2
LENS & VIEW ANGLE : 0.5mm F1.2 /55 °
Dimensions(LXWXH): 9.5 x 9.5 x 18mm (smallest)
POWER SUPPLY: DC5V  30mA
VIDEO OUT: 1.0V p-p/75ohm

Usage:
1) CCTV cameras can be used directly with a standard TV/VCR or RCA video monitor
2) To view more than one CCTV camera on your TV/VCR you will need a quad or multiplexer
3) To view on your computer or laptop you will need a DVR card or USB
4) A standalone system that records is a standalone DVR
5) CCTV wired cameras can add a 2.4GHz wireless transmitter module,then it can work with wireless receivers.
